MIRACLE 传统油石
EDM-BR
一般模具丶铸铁模及放电加工後的表面研磨
詳細介紹

由高密度且耐磨 WA 磨粒经由特殊树脂加工而成。具有良好的切削力且磨损较小,不易因磨削而变形。适用于细部研磨、粗加工到半精加工的修饰。

用途 : 一般模具、铸铁模及放电加工后的表面研磨。



粒度

#120、#180#240#320#400#600#800#1000#1200


尺寸

1x10x100、3x6x100、3x6x150、3x13x150、5x13x150、6x6x150



尺寸: 1 x 10 x 100mm (矩形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR110100-120 PS-EDM-BR110100-180 PS-EDM-BR110100-240 PS-EDM-BR110100-320 PS-EDM-BR110100-400 PS-EDM-BR110100-600 PS-EDM-BR110100-800 PS-EDM-BR110100-1000 PS-EDM-BR110100-1200

尺寸: 3 x 6 x 100mm (矩形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR36100-120 PS-EDM-BR36100-180 PS-EDM-BR36100-240 PS-EDM-BR36100-320 PS-EDM-BR36100-400 PS-EDM-BR36100-600 PS-EDM-BR36100-800 PS-EDM-BR36100-1000 PS-EDM-BR36100-1200

尺寸: 3 x 6 x 150mm (矩形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR36150-120 PS-EDM-BR36150-180 PS-EDM-BR36150-240 PS-EDM-BR36150-320 PS-EDM-BR36150-400 PS-EDM-BR36150-600 PS-EDM-BR36150-800 PS-EDM-BR36150-1000 PS-EDM-BR36150-1200

尺寸: 3 x 13 x 150mm (矩形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR313150-120 PS-EDM-BR313150-180 PS-EDM-BR313150-240 PS-EDM-BR313150-320 PS-EDM-BR313150-400 PS-EDM-BR313150-600 PS-EDM-BR313150-800 PS-EDM-BR313150-1000 PS-EDM-BR313150-1200

尺寸: 5 x 13 x 150mm (矩形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR513150-120 PS-EDM-BR513150-180 PS-EDM-BR513150-240 PS-EDM-BR513150-320 PS-EDM-BR513150-400 PS-EDM-BR513150-600 PS-EDM-BR513150-800 PS-EDM-BR513150-1000 PS-EDM-BR513150-1200

尺寸: 6 x 6 x 150mm (方形)
#120 #180 #240
#320
#400 #600 #800 #1000 #1200
PS-EDM-BR66150-120 PS-EDM-BR66150-180 PS-EDM-BR66150-240 PS-EDM-BR66150-320 PS-EDM-BR66150-400 PS-EDM-BR66150-600 PS-EDM-BR66150-800 PS-EDM-BR66150-1000 PS-EDM-BR66150-1200
